Streamline design appearance,sure thin,easy stallation, less weight to save your shipping cost,extremly high brightness, final finished product's luminous can reach 130-140lm/w.
Product specification | |
Model No. | SW-FL600D-W150 |
Rated Power | 150W |
Input Voltage | AC100-277V, 50/60Hz, 0.91A(at 230v); 347/480v for option |
PF: | >0.97 |
IP Grade: | IP66 |
THD: | 10%(at 230v, 50Hz) |
Surge protection: | L/N-PE: 6KV, L-N: 4KV; 10/20KV version is for option. |
LED Parameters | |
LED chip | SMD3030 LED |
Light Efficiency | 130-140lm/w |
Color Temperature | 2700-7000k |
CRI | >70Ra or 80Ra |
Beam Angle | 30°, 60°, 90°, Type 2 (70*150°), Type 3 (80*150°), Type 4 (50*140°), Type 5 (140*140°)
120*120° |
Mechanical Specification | |
Body Material | Aluminum |
Lens Material | Glass lens |
Body color | Black |
Operating Temperature | -35℃ – 50℃ |
Net W./Gross W | 5.6KGS / 6.8KGS(one piece) |
Packing size | 54*46*18CM, 1pc in one carton |
Warranty | 5 years warranty |
Certificates | CE, RoHS, SAA, LM80, LM79 |
Led flood light 150w widely used in shopping mall, billboard, exhibition hall, parking lot, tennis court,
gymnasium, park, garden, building facade, any indoor or outdoor areas.
