Patent housing design with perfect heat dissipation.Different beam angle 120°*120°, 60°*120°, 90°*120°.Two mounting type:suspending mounting and bracket mounting for option.Simple and pretty appearance, exclusive high-end products. Surely will bring you incomparable refreshing experience.
| Product specification | |
| Model No. | SW-L500-W240 |
| Rated Power | 240W |
| Input Voltage | AC100-277V, 50/60Hz, 0.45A(at 220v)； 347/480V AC for option |
| PF: | >0.97 |
| IP Grade: | IP65 |
| THD: | 10%（at 230v, 50Hz) |
| Surge protection: | L/N-PE: 6KV, L-N: 4KV; 20KV version is for option. |
| LED Parameters | |
| LED chip | SMD3030 LED |
| Light Efficiency | 140-150lm/w |
| Color Temperature | 2700-7000k |
| CRI | >70Ra or 80Ra |
| Beam Angle | 120°x120°; 60°x100°；30°x100° |
| Mechanical Specification | |
| Body Material | Aluminum |
| Lens Material | PC lens |
| Body color | White/grey |
| Operating Temperature | -35℃ – 50℃ |
| Net W./Gross W | 6.0KGS / 7.0KGS(one piece) |
| Packing size | 62x39x17CM, One piece in one carton |
| Warranty | 5-7 years warranty |
| Certificates | CE, RoHS, SAA, ETL, DLC |
Warning:
Application
(1). Warehouse,factory and workshops;
(2). Highway toll station and gas station;
(3). Exhibition hall and supermarket;
(4). Gymnasium and supermarket;
(5). Residential area, etc.
Tell us your needs and our professional in-house engineers will give you professional lighting solutions including specific parameters which is more than satisfaction.
One-stop shop for your lighting projects; Lamp body, lighting performance, material of lights,etc. all can be tailored to your specific requirements. Tell us your ideas, we make it real.
Time is money. We are deeply aware of what time means to your business. Standard orders are shipped within 1 week from getting your orders. Cooperate with SNOOWEL, coordinate with your schedule.
Each and every light is backed up with long warranty period of 5-7 years. Any concern including LED lights and components are covered in it. Our after-sales support team is always ready to help you.
